0/1-10V Dimmable LED Tri-proof Lighting AL Housing 600mm 30w 3150Lm 4000K

Control type: 0-10V

0-10 V is one of the earliest and simplest electronic lighting control signaling systems; simply put, the control signal is a DC voltage that varies between zero and ten volts. The controlled lighting should scale its output so that at 10 V, the controlled light should be at 100% of its potential output, and at 0 V it should at 0% output (i.e. “Off”). Dimming devices may be designed to respond in various patterns to the intermediate voltages, giving output curves that are linear for: voltage output, actual light output, power output, or perceived light output.

A typical 0-10V wiring diagram is shown below:

Control type: 1-10V

Continuous dimming via analog control signal.

1-10V feature enables analog dimming in a step-less manner. Light levels can be set anywhere between 10% to 100% of light output. By connecting a 1-10V equiped driver to a light point controller, the feature can provide continuous dimming. When combined with a switch device unit (SDU), 1-10 V duplicates the dimming function of LineSwitch for cabinet control.

A typical 1-10V wiring diagram is shown below:

Product benefits

• Functional design
• High light output thanks to high-power LED
• Quick and simple installation
• With exceptional rated lifetimes
• Zero restrike time
• A compact lightweight construction
• Provides additional benefits of energy savings
• Significantly reduced relamp maintenance costs.

Areas of application

• Suitable for indoor and outdoor applications
• Commercial lighting: Supermarket/Shops/Exhibition hall/Parking place/gas station;
• Public lighting: library/School/Tunnel/Metro/Bus/Train/Bus station, railway/station, airport;
• Industrial lighting: Factory/Warehouse and Etc.

Product features

• Waterproof, dust-proof, corrosion proof
• Type of protection: IP65
• Efficacy up to 130 LPW
• Input Voltage: 85-265VAC
• Powerfactor(PF):>95%
• Epistar Chip
